TINI LED Surface Spot Light
Elegant and compact design, with high efficiency and color rendering, excellent anti-glare con trol, which can meet various of requirements for lighting solutions. It is widely applicable for shopping mall, cloth store, exhibition or display area and etc... Die-casting aluminium housing. Powder coated finish. High transparacny lens optic, minimized glare light efficiently. Built-in driver. Surface mounted. Horizontally and vertically Adjustable. Easy for installation and maintenance.
Product specifications
Luminaire Type:TINI LED Surface Spot Light
Luminaire Code :82000018/82018958
Input Voltage:220-240V
Wattage:10-15W
Size:Dia 56*H150 mm
Beam Angle:15°/24°/40°
Materials:Aluminium
Finish:Powder coated
Product Features
Line diagram
Optional Accessories
Reflector color
Frame Color
TYPE
Power
- Power
- 10
- 15
Beam Angle
- Beam Angle
- 15
- 24
- 40
CRI
- CRI
- >90
Color Temperature
- Color Temperature
- 2700
- 3000
- 4000
- 5000
Optional Accessories
- Optional Accessories
Dimming Method
- Dimming Method
- 1-Non Dim
- 2-Phase dimming
- 3-0-10V dimming
- 4-DALI dimming
Frame Color
- Frame Color
- Grey.png
- White.png
- Black.png
Reflector Color
- Reflector Color
Protection Grade
- Protection Grade
- IP 20
Model
82000018
82000018
82000018
82000018
82000018
82000018
82000018
82000018
82000018
82000018
82000018
82000018
82018958
82018958
82018958
82018958
82018958
82018958
82018958
82018958
82018958
82018958
82018958
82018958
Luminous
Flux
Flux
(LM)
821.5
839.1
855.7
860.0
878.4
895.8
911.3
930.8
949.3
949.8
970.2
989.4
1131.9
1158.3
1190.0
1185.0
1212.6
1245.8
1255.7
1285.0
1321.2
1308.8
1339.3
1377.0
Power
(W)
10
10
10
10
10
10
10
10
10
10
10
10
15
15
15
15
15
15
15
15
15
15
15
15
Beam
Angle
Angle
(°)
15
24
40
15
24
40
15
24
40
15
24
40
15
24
40
15
24
40
15
24
40
15
24
40
CRI
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
>90
Color
Temperature
Temperature
(K)
2700
2700
2700
3000
3000
3000
4000
4000
4000
5000
5000
5000
2700
2700
2700
3000
3000
3000
4000
4000
4000
5000
5000
5000
Specification
IES
Instruction
Manual
Manual
Project Application
